Camera Image Sensor 1/2.8″ STARVIS™ CMOS Pixel 4MP Max. Resolution 2560 (H) × 1440 (V) ROM 4GB RAM 1GB Electronic Shutter Speed 1/1 s–1/30,000 s Scanning System Progressive Min. Illumination Color: [email protected] B/W: [email protected] [email protected] (IR light on) Illumination Distance 100 m (328.08 ft) Illuminator On/Off Control Zoom Prio/Manual/SmartIR Illuminator Number 4 Lens Focal Length 4.8 mm–120 mm Max. Aperture F1.6–F4.0 Field of View H: 60.0°–2.5°; V: 30.8°–2.2°; D: 66.7°–2.9° Optical Zoom 25x Focus Control Auto/Semi-Auto/Manual Close Focus Distance 0.1 m–1.5 m (0.33 ft–4.92 ft) Iris Control Auto/Manual DORI Distance Detect Observe Recognize Identify 2540 m (8333.33 ft) 1016 m (3333.33 ft) 508 m (1666.67 ft) 254 m (833.33 ft) PTZ Pan/Tilt Range Pan: 0°–360° (endless) Tilt: -15°–90° (auto flip 180°) Manual Control Speed Pan: 0.1°–200°/s Tilt: 0.1°–120°/s Preset Speed Pan: 240°/s Tilt: 200°/s Presets 300 Tour 8 (up to 32 presets per tour) Pattern 5 Scan 5 Speed Adjustment Support Power-off Memory Support Idle Motion Preset/Tour/Pattern/Scanning Protocol DH-SD Pelco-P/D (auto recognition) General Intelligence Event Trigger Motion detection, Video tampering, Scene changing, Network disconnection, IP address conflict, Illegal Access, Storage anomaly IVS Object Abandoned/Missing Artificial Intelligence Perimeter Protection Tripwire and intrusion. Support alarm triggering by target types (human and vehicle). Support filtering false alarms caused by animals, rustling leaves, bright lights, etc. SMD PLUS Support Face Detection Support Smart Capture Support human, motor vehicle and non-motor vehicle image capture. Video Compression H.265 /H.265/H.264 /H.264/MJPEG (sub stream) Streaming Capability 3 streams Resolution 4M (2560 x 1440); 3M (2048 x 1536); 1080P (1920 x 1080); 1.3M (1280 x 960); 720P (1280 × 720); D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240) Frame Rate Main stream: 4MP/3MP/1080P/1.3MP/720P (1–25fps) Sub stream 1: D1/CIF (1–25fps) Sub stream 2: 1080P/1.3M/720P (1–25fps) Bit Rate Control Variable/Constant Bit Rate H.265/H.264: 3 kbps–20480 kbps Day/Night Auto(ICR)/Color/B/W BLC Support WDR 120 dB HLC Support White Balance Auto/Indoor/Outdoor/Track/Manual/Sodium lamp/Natural light/Street lamp Gain Control Auto/Manual Noise Reduction Ultra DNR (2D/3D) Motion Detection Support Region of Interest Support Electronic Image Stabilization Support Electronic Defog Support Digital Zoom 16x Flip 180° Privacy Masking Up to 24 areas, and up to 8 areas in the same view Audio Compression G.711a; G.711Mu; AAC; G.722.1; G.726; MPEG2-Layer2; G.729 Network Ethernet RJ-45 (10/100Base-T) Protocol IPv4; IPv6; HTTP; HTTPS; SSL; TCP/IP; UDP; UPnP; ICMP; IGMP; SNMPv1/v2c/v3(MIB-2); ARP; RTCP; RTSP; RTP; SMTP; NTP; DHCP; DNS; PPPOE; DDNS; FTP; IP Filter; QoS; Bonjour; 802.1x Interoperability ONVIF Profile S&G&T; CGI Streaming Method Unicast/Multicast User/Host 20 Storage NAS; Local PC; Micro SD card (256G) Browser IE7 and newer versions Chrome 45 and earlier versions Firefox 52 and earlier versions Safari (no version restrictions) Management Software Smart PSS; DSS; DMSS Mobile Phone IOS/Android Certification Certifications CE: EN55032/EN55024/EN50130-4 FCC: Part15 subpartB, ANSI C63.4-2014 UL: UL62368-1 CAN/CSA C22.2,No. 62368-1 Port Audio Input 1 Audio Output 1 Alarm I/O 2/1 Power Power Supply DC 12V/3A PoE (802.3at) Power Consumption 13W 21W (IR on) Environment Operating Temperature -40°C to 70°C (-40°F to 158°F) Operating Humidity ≤95% Protection IP66; TVS 6000V lightning proof; Surge protection Structure Dimensions Φ160 mm × 295 mm (6.30″ × 11.61″) Net Weight 3 kg (6.61 lb) Gross Weight 4.8kg (10.58lb)
