Camera Image Sensor 1/2.8″ CMOS Pixel 4 MP Max. Resolution 2560 (H) × 1440 (V) ROM 4 GB RAM 1 GB Electronic Shutter Speed 1/1 s–1/30,000 s Scanning System Progressive Min. Illumination Color: 0.005 [email protected]; B/W: 0.0005 [email protected]; 0 [email protected] (IR on) Illumination Distance 250 m (820.21 ft) Illuminator On/Off Control Zoom Prio; Manual; Smart IR; Off Illuminator Number 6 (IR) Lens Focal Length 3.95 mm–177.75 mm Max. Aperture F1.6–F4.95 Field of View H: 70.3°–1.8°; V: 37°–1°; D: 69.3°–2° Optical Zoom 45× Focus Control Auto/Semi-Auto/Manual Close Focus Distance 0.1 m–1 m (0.33 ft–3.28 ft) Iris Control Auto/Manual DORI Distance Detect Observe Recognize Identify 3,555 m (11,663.39 ft) 1,404.2 m (4,606.96 ft) 711 m (2,332.68 ft) 355.5 m (1,166.34 ft) DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool. PTZ Pan/Tilt Range Pan: 0° to 360° endless Tilt: –20° to 90°, auto flip 180° Manual Control Speed Pan: 0.1°/s–300°/s; Tilt: 0.1°/s–200°/s Preset Speed Pan: 400°/s; Tilt: 300°/s Preset 300 Tour 8 (up to 32 presets per tour) Pattern 5 Scan 5 Power-off Memory Yes Idle Motion Pattern; Preset; Scan; Tour PTZ Protocol DH-SD Pelco-P/D (auto recognition) Intelligence Video Metadata Detects motor and non-motor vehicles, faces and human bodies. It also performs tracking, takes snapshots, uploads high-quality face images and optimizes images. It extracts attributes from motor vehicles, detecting up to 10 attributes for them. IVS (Perimeter Protection) Tripwire; intrusion; climbing fences; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; vehicle/human alarm classification; linkage tracking Face Detection Supports face detection, optimization, tracking, capturing pictures, uploading high-quality face snapshots, and face enhancement; Supports attributes extraction. 6 attributes and 8 expressions: Gender, age, glasses, expressions (angry, sad, hate, scary, surprise, calm, happy and confused), mask, mustache; Supports face cutout: Face, one-inch photo. Capturing strategies include real-time capturing, optimization, and quality first. Construction Detection Detects 6 helmet colors: Red, orange, yellow, blue, white, and black. An alarm will be triggered when a person is not wearing a helmet or when the color of the helmet that they are wearing does not match the configured color. It also supports compliance detection for work uniforms. Up to 5 work uniform sample libraries can be uploaded, which together can contain up to 1,000 images (the images must be 1080p and in the JPG format). An alarm will be triggered when the similarity between the detected work uniform and the samples in the library is below the set threshold (that is, below the minimum compliance standard for work uniforms). The system supports detecting the attributes of work uniforms such as the color of the uniform, and whether or not the person is wearing a mask and wearing shoe covers. An alarm will be triggered when the target is detected as not meeting the set requirements. It also detects and triggers alarms when only one person is in the construction site, and when no one is present in the detection area such as when a worker leaves their post or an area is left unmanned. Auto Tracking Yes SMD SMD 4.0 Acupick Uses deep learning algorithms and works with back-end devices to accurately match targets, such as people and motor vehicles, and search through live and recorded videos to quickly locate targets. Auto Patrol It triggers the IVS rule when a target is detected and makes the camera link with the PTZ to rotate to the position of the target and patrol based on its presets. Video Video Compression H.264H; H.264B; Smart H.265 ; H.264; H.265; MJPEG(Sub Stream); Smart H.264 Streaming Capability 3 streams Resolution 4M (2560 × 1440); 3M (2048 × 1536); 3M (2304 × 1296); 1080p (1920 × 1080); 720p (1280 × 720); D1 (704 × 576); VGA (640 × 480); CIF (352 × 288) Video Frame Rate Main stream: 4M/3M/1080p/1.3M/720p (1–25/30 fps) Sub stream 1: D1/VGA/CIF (1–25/30 fps) Sub stream 2: 1080p/1.3M/720p (1–25/30 fps) Bit Rate Control CBR/VBR Video Bit Rate H264: 96 kbps–14848 kbps H265: 38 kbps–8960 kbps Day/Night Auto (ICR)/Color/B/W BLC Yes WDR 120 dB HLC Yes White Balance Auto; Indoor; Outdoor; ATW; Manual; Sodium Lamp; Natural Light; Street Lamp Gain Control Auto/Manual Noise Reduction 2D/3D Motion Detection Yes Region of Interest (RoI) Yes Image Stabilization Electronic (EIS) Defog Electronic Digital Zoom 16× Image Rotation 180° Privacy Masking Up to 24 areas can be set, with up to 8 areas in the same view S/N Ratio ≥ 55 dB Audio Audio Compression PCM; G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1; G729; G723 Network Network Port 1 × RJ-45 (10/100 Base-T) Network Protocol FTP; RTMP; IPv6; Bonjour; IPv4; DNS; RTCP; PPPoE; NTP; RTP; 802.1x; HTTPS; SNMP; TCP/IP; DDNS; UPnP; NFS; ICMP; UDP; IGMP; HTTP; SSL; DHCP; SMTP; Qos; RTSP; ARP Interoperability CGI; SDK; ONVIF (Profile S&G&T); P2P Streaming Method Unicast/Multicast User/Host 20 (total bandwidth: 64 M) Storage Micro SD card (Up to 512 GB);FTP;NAS Browser IE 9 and later versions Chrome 41 and later versions Firefox 50 and later versions iOS 10 and later versions Management Software DSS; DMSS Mobile Client iOS; Android Certification Certifications CE: EN55032/EN55024/EN50130-4 FCC: Part15 subpartB, ANSI C63.4- 2014 Port Analog Output 1 channel (CVBS output, BNC) RS-485 1(Bit range: 1200 bps–9600 bps) Audio Input 1 channel Audio Output 1 channel Alarm Linkage Capture; recording; send email; preset; tour; pattern; alarm digital output Alarm Event Motion/Tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection Alarm I/O 7/2 Audio I/O 1/1 Power Power Supply 24 VDC, 2.5 A ± 25% PoE (802.3at) Power Consumption Basic: 13 W Max: 25 W Environment Operating Temperature –40 °C to 70 °C (–40 °F to 158 °F) Operating Humidity ≤ 95% (RH) Protection IP67; IK10; TVS 6000V lightning proof; surge protection; voltage transient protection Structure Product Dimensions 337.4 mm × Φ209 mm (13.28″ × Φ8.23″) Net Weight 5.9 kg (13.00 lb) Gross Weight 9.6 kg (21.16 lb)
